Sidewall Belt Vulcanizing Press

Sidewall Belt Vulcanizing Press

Qingdao Shun Cheong Machinery Co., Ltd is the professional manufacturer of various vulcanizing press and press machine. Our company has passed ISO9001:2008 Quality Management System Certification and our products have qualified with Sweden SGS Certificate and CE Certificate.



Sidewall Belt Vulcanizing Press is used to combine and vulcanize vulcanized parallel conveyor belts, belt shirt and belt clapboard into side wall belts.



Plates are constituted with welded Q235 steel plates through mechanical ball blast rust removal, spraying zinc rich series paint, shake to remove stress, then transferred into mechanical producing.



Hot plates are obtained by 35# steel plates after normalizing handling and then adopting double scale rolling. It is equipped with a set of electric control valves to realize the automatic adjusting of steaming temperature.



Up and down platforms adopts Q235 steel plates. In order to guarantee the make precision, it is applied with automatic cutting baiting, mechanical slicer producing welded groove, carbon dioxide gas shielded welding. It all adopts alloy welding wire welding and after welding takes whole enter into stove to go on the hot treatment to remove the welding stress exhaustively. And then go on mechanical producing to guarantee it won't become deformed.



Hydro-cylinder adopts ZG270-500 and piston stroke adopts hard cold chilled alloy cast iron. And sealing structure applies the combined structure with double sealing ring and one dustproof ring to guarantee longer service.



Auxiliary driven roller is moveable type and it can move at any time according to different length of belts and then fixed.



Hydraulic stretching roll works through the hydraulic pressure to stretch the vulcanized side wall belts. There is the electric drive system to move the belt to fit and vulcanize shirt side and clapboard and go on to finish the vulcanizing of the whole side wall conveyor belt.



Before leaving factory, this vulcanizing press needs to pass 24 hours' pressure test, pressure maintaining to test the bearing of the hydro-cylinder and piston stroke and guarantee no oil leakage and seeping to avoid unnecessary quality problems.



We can design and manufacture all kinds of non-standard vulcanizing machine according to the customers' definite requirements.
